Dimensionamento de um cristalizador assistido por destilação com membranas para recuperação de água de efluentes salinos com descarte zero de líquido

Emanuelly Felix Gaigher; Yuri Nariyoshi

doi:10.47456/bjpe.v11i2.46112

Autores

Emanuelly Felix Gaigher Universidade Federal do Espírito Santo (UFES) Autor https://orcid.org/0009-0009-0345-9136
Yuri Nariyoshi Universidade Federal do Espírito Santo (UFES) Autor https://orcid.org/0000-0001-8523-4292

DOI:

https://doi.org/10.47456/bjpe.v11i2.46112

Palavras-chave:

Dimensionamento, Cristalização, Dessalinização

Resumo

A escassez de água é um problema global que vem se intensificando, fazendo com que as indústrias busquem estratégias para reduzir a captação de água e o descarte de efluentes. Este trabalho tem como objetivo criar um cristalizador associado à destilação por membranas para a recuperação de água de efluentes salinos, com o objetivo de minimizar o desperdício de líquidos. A otimização do processo de destilação por membranas com cristalização (MDC) foi empregada a fim de potencializar a recuperação de água e sais. O cristalizador proposto foi desenvolvido para trabalhar em sinergia com o módulo de membranas, possibilitando a separação eficiente da água e dos sais como subprodutos. Todos os resultados obtidos são viáveis do ponto de vista industrial, o que corrobora essa afirmação.

Downloads

Os dados de download ainda não estão disponíveis.

Biografia do Autor

Yuri Nariyoshi, Universidade Federal do Espírito Santo (UFES)

Bachelor and Doctor degree in Chemical Engineering (respectively at UFES, Brazil, 2011, and USP, Brazil, 2016). Adjunct Professor in the Department of Engineering and Technology at UFES since 2016. Has experience in the field of thermodynamics of separation processes, especially in crystallization and membrane distillation. Currently deputy chief of the Department of Engineering and Technology at UFES.

Referências

Alklaibi, A. M. & Lior, N. (2005) Membrane-distillation desalination: Status and potential. Desalination 171(2), 111-131. https://doi.org/10.1016/j.desal.2004.03.024

Ayoub, G. M., Korban, L., Al-Hindi, M., & Zayyat, R. (2018). Removal of fouling species from brackish water reverse osmosis reject stream. Environmental Technology, 39(6), 804-813. https://doi.org/10.1080/09593330.2017.1311946

Barnea, E. & Mizrahi, J. (1973) A Generalized Approach to the Fluid Dynamics of Particulate Systems Part 1. General Correlation for Fluidization and Sedimentation in Solid Multiparticle Systems. The Chemical Engineering Journal, 5(2), 171-189. https://doi.org/10.1016/0300-9467(73)80008-5

Binev, D., Seidel-Morgenstern, A., & Lorenz, H. (2015). Study of crystal size distributions in a fluidized bed crystallizer. Chemical Engineering Science, 133, 116-124. https://doi.org/10.1016/j.ces.2014.12.041

Curcio, E., Ji, X., Quazi, A. M., Barghi, S., Profio, G. D., Fontananova, E., Macleod, T., & Drioli, E. (2010) Hybrid nanofiltration-membrane crystallization system for the treatment of sulfate wastes. Journal of Membrane Science, 360(1-2), 493-498. https://doi.org/10.1016/j.memsci.2010.05.053

Curcio, E., Criscuoli, A., & Drioli, E. (2001). Membrane Crystallizers. Industrial & Engineering Chemistry Research, 40(12), 2679-2684. https://pubs.acs.org/doi/10.1021/ie000906d

Giulietti, M., Seckler, M. M., Derenzo, S., Ré, M. I., & Cekinski, E. (2001). Industrial crystallization and precipitation from solutions: State of the technique. Brazilian Journal of Chemical Engineering, 18(4), 423-440. https://doi.org/10.1590/S0104-66322001000400007

Ji, X., Curcio, E., Obaidani, S. A., Profio, G. D., Fortananova, E., & Drioli, E. (2010). Membrane distillation-crystallization of seawater reverse osmosis brines. Separation and Purification Technology, 71(1), 76-82. https://doi.org/10.1016/j.seppur.2009.11.004

Jiang, X., Tuo, L., Dapeng, I., Hou, B., Chen, W., & He, G. (2017). Progress in membrane distillation crystallization: Process models, crystallization control and innovative applications. Frontiers of Chemical Science and Engineering, 11(4), 647-662. http://dx.doi.org/10.1007/s11705-017-1649-8

Lewis, A., Seckler, M., Kramer, H., & Rosmalen, G. (Ed.). (2015) Industrial crystallization: Fundamentals and applications. Cambridge: Cambridge University Press

Madwar, K. & Tarazi, H. (2003). Desalination techniques for industrial wastewater reuse. Desalination, 152(1-3), 325-332. https://doi.org/10.1016/S0011-9164(02)01080-9

Mezher, T., Fath, H., Abbas, Z., & Khaled, A. (2011). Techno-economic assessment and environmental impacts of desalination technologies. Desalination, 266(1–3), 263-273. https://doi.org/10.1016/j.desal.2010.08.035

Nalesso, S., Bussemaker, M. J., Sear, R. P., Hodnett, M., & Lee, J. (2018). Development of Sodium Chloride Crystal Size during Antisolvent Crystallization under Different Sonication Modes. Crystal Growth & Design. 19(1), 141-149. https://doi.org/10.1021/acs.cgd.8b01172

Nariyoshi, Y. N., Pantoja, C. E., & Seckler, M. M. (2016). Evaluation of sodium chloride crystallization in membrane distillation crystallization applied to water desalination. Brazilian Journal of Chemical Engineering, 33(3). https://doi.org/10.1590/0104-6632.20160333s20150133

Nývlt, J., Hostomský, J., & Giulietti, M. (2001). Cristalização. Cap. 5, 95-110pp. São Carlos: EdUFSCar.

Pantoja, C. E., Nariyoshi, Y. N., & Seckler, M. M. (2015). Membrane Distillation Crystallization Applied to Brine Desalination: A Hierarchical Design Procedure. Industrial and Engineering Chemistry Research, 54(10), 2776-2793. https://doi.org/10.1021/ie504695p

Quist-Jensen, C. A., Macedonio, F., & Drioli, E. (2016). Membrane crystallization for salts recovery from brine - an experimental and theoretical analysis. Desalination and Water Treatment, 57(16), 7593-7603. https://doi.org/10.1080/19443994.2015.1030110

Seader, J. D., Henley, E. J., & Roper, D. K. (Ed.). (2016). Separation Process Principles: With Applications Using Process Simulators. Nova Jersey: Wiley.

Seckler, M. M., Nariyoshi, Y. N., Pantoja, C. E., Zacharias, L. C., & Penha, F. M. (2016). Tecnologias para descarte zero de efluentes líquidos industriais. Recuperado de https://repositorio.usp.br/directbitstream/e8cac106-2ff0-4bcf-85f8-5a74f12bf5dd/3037544.pdf

Tijing, L. D., Woo, Y. C., Choi, J., Lee, S., Kim, S., & Shon, H. K. (2015). Fouling and its control in membrane distillation-A review. Journal of Membrane Science, 475, 215-244. http://dx.doi.org/10.1016/j.memsci.2014.09.042

United Nations. (2021). The United Nations World Water Development Report 2021: Valuing Water. Recuperado de https://unesdoc.unesco.org/ark:/48223/pf0000375751

United Nations Statistics Division. (2022). The Sustainable Development Goals Report 2022. Recuperado de https://unstats.un.org/sdgs/report/2022

Warsinger, D. M., Swaminathan, J., Guiellen-Burrieza, E., Arafat, H. A., & Lienhard V, J. H. (2015). Scaling and fouling in membrane distillation for desalination applications: A review. Desalination, 356, 294-313. https://doi.org/10.1016/j.desal.2014.06.031

Wu, Y., Kong, Y., Liu, J., Zhang, J., & Xu, J. (1991). An Experimental Study on Membrane Distillation-Crystallization for Treating Wastewater in Taurine Production. Desalination. 80, 235-242. https://doi.org/10.1016/0011-9164(91)85160-V
